Intel Wi-Fi 7 BE200 Internal WLAN / Bluetooth 5800 Mbit/s
Intel Wi-Fi 7 BE200 Internal WLAN / Bluetooth 5800 Mbit/s
Regular price
£40.32 GBP
Regular price
Sale price
£40.32 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:BE200.NGWG.NV
13 in stock
- Wireless
- M.2 WLAN / Bluetooth
- 5800 Mbit/s
- Wi-Fi Tri-band (2.4 GHz / 5 GHz / 6 GHz) Bluetooth 5.4
- Internal Component for: PC/Laptop
Intel WiFi 7 BE200
Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wireless |
| Host interface | M.2 |
| Interface | WLAN / Bluetooth |
| Network | |
|---|---|
| Maximum data transfer rate | 5800 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w |
| Wi-Fi | Yes |
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Security algorithms | AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3 |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| MU-MIMO | Yes |
| Design | |
|---|---|
| Internal | Yes |
| Component for | PC/Laptop |
| Antenna type | 2x2 |
| System requirements | |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11 |
| Linux operating systems supported | Yes |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 80 °C |
| Sustainability | |
|---|---|
| Sustainability compliance | Yes |
| Weight & dimensions | |
|---|---|
| Width | 22 mm |
| Depth | 30 mm |
| Height | 2.4 mm |
| Weight | 3.07 g |
| Technical details | |
|---|---|
| Compliance certificates | CB, UL |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8517620090 |
| Other features | |
|---|---|
| Maximum operating temperature | 70 °C |
| Compliance | FIPS |
| Supported Under vPro | Yes |
| Embedded options available | No |
| Intel Trusted Execution Technology | No |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Export Control Classification Number (ECCN) | 5A992C |
| Ethernet adapter ARK ID | 230078 |
| Status | Launched |
| Product brief URL | https://www.intel.com/content/www/us/en/secure/content-details/916611/intel-wi-fi-7-be200-5gig-module-commercial-temperature-embedded-module-product-brief.html?DocID=916611 |
| Launch date | Q3'23 |
