Maximum internal memory supported by processor: 192 GB DDR5-SDRAM
Tray
Intel Core Ultra 5 processor 225F (20M Cache, up to 4.90 GHz) FCLGA18W, Tray
The latest Intel® Core™ Ultra processors (Series 2) enable you to use the most AI experiences across desktop, mobile and edge—making everything you do easier, faster, and better.
Processor
Processor manufacturer
Intel
Processor family
Intel Core Ultra 5
Processor generation
Intel Core Ultra (Series 2)
Processor model
225F
Processor cores
10
Processor socket
LGA 1851 (Socket V1)
Processor threads
10
Processor operating modes
64-bit
Performance cores
6
Efficient cores
4
Processor boost frequency
4.9 GHz
Performance-core boost frequency
4.9 GHz
Performance-core base frequency
3.3 GHz
Efficient-core boost frequency
4.4 GHz
Efficient-core base frequency
2.7 GHz
Processor cache
20 MB
Processor cache type
Smart Cache
Maximum turbo power
121 W
Processor base power
65 W
AI software frameworks supported by CPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum number of DMI lanes
8
Processor codename
Arrow Lake
Processor ARK ID
241069
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Sparsity support
Yes
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to
19 TOPs
NPU performance up to
13 TOPs
Memory
Maximum internal memory supported by processor
192 GB
Memory types supported by processor
DDR5-SDRAM
Memory clock speeds supported by processor
6400 MHz
Memory channels
Dual-channel
Graphics
Discrete graphics card
No
On-board graphics card
No
On-board graphics card model
Not available
Discrete graphics card model
Not available
Features
Thermal Monitoring Technologies
Yes
Idle States
Yes
Execute Disable Bit
Yes
Market segment
Desktop
Use conditions
PC/Client/Tablet
Maximum number of PCI Express lanes
24
PCI Express slots version
4.0, 5.0
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Direct Media Interface (DMI) Revision
4.0
Embedded options available
No
Scalability
1S
Processor special features
Intel® Speed Shift Technology
Yes
Intel Trusted Execution Technology
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Turbo Boost Technology
2.0
Intel® Thunderbolt 4
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Thread Director
Yes
Intel® Standard Manageability (ISM)
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Deep Learning Boost (Intel® DL Boost)
Yes
Intel® Boot Guard
Yes
Intel® OS Guard
Yes
Intel® Secure Key
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
