Intel
Regular price
£178.00 GBP
Regular price
Sale price
£178.00 GBP
Unit price
/
per
Sale
Sold out
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Refresh
SKU: AT8076806415
Low stock: 9 left
Intel Core Ultra 5 225
20 MB Smart Cache LGA 1851 (Socket V1)
Processor cores: 10 64-bit
Maximum internal memory supported by processor: 192 GB DDR5-SDRAM
On-board graphics card Intel® Graphics
Tray
Intel Core Ultra 5 processor 225 (20M Cache, up to 4.90 GHz) FCLGA18W, Tray
The latest Intel® Core™ Ultra processors (Series 2) enable you to use the most AI experiences across desktop, mobile and edge—making everything you do easier, faster, and better.
Processor
Processor manufacturer
Intel
Processor family
Intel Core Ultra 5
Processor generation
Intel Core Ultra (Series 2)
Processor model
225
Processor cores
10
Processor socket
LGA 1851 (Socket V1)
Processor threads
10
Processor operating modes
64-bit
Performance cores
6
Efficient cores
4
Processor boost frequency
4.9 GHz
Performance-core boost frequency
4.9 GHz
Performance-core base frequency
3.3 GHz
Efficient-core boost frequency
4.4 GHz
Efficient-core base frequency
2.7 GHz
Processor cache
20 MB
Processor cache type
Smart Cache
Maximum turbo power
121 W
Processor base power
65 W
AI software frameworks supported by CPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum number of DMI lanes
8
Processor codename
Arrow Lake
Processor ARK ID
241070
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Sparsity support
Yes
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to
23 TOPs
NPU performance up to
13 TOPs
GPU performance up to
4 TOPs
Memory
Maximum internal memory supported by processor
192 GB
Memory types supported by processor
DDR5-SDRAM
Memory clock speeds supported by processor
6400 MHz
Memory channels
Dual-channel
Graphics
Discrete graphics card
No
On-board graphics card
Yes
On-board graphics card model
Intel® Graphics
On-board graphics card outputs supported
HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1
On-board graphics card base frequency
300 MHz
On-board graphics card dynamic frequency (max)
1800 MHz
Number of displays supported (on-board graphics)
4
On-board graphics card OpenGL version
4.5
On-board graphics card DirectX version
12.0
On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card ID
0x7D67
Discrete graphics card model
Not available
Xe-cores
2
Features
Thermal Monitoring Technologies
Yes
Idle States
Yes
Execute Disable Bit
Yes
Market segment
Desktop
Use conditions
PC/Client/Tablet
Maximum number of PCI Express lanes
24
PCI Express slots version
4.0, 5.0
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Direct Media Interface (DMI) Revision
4.0
Embedded options available
Yes
Scalability
1S
Processor special features
Intel® Quick Sync Video Technology
Yes
Intel® Speed Shift Technology
Yes
Intel Trusted Execution Technology
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Turbo Boost Technology
2.0
Intel® Thunderbolt 4
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Thread Director
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Yes
Intel® Standard Manageability (ISM)
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Deep Learning Boost (Intel® DL Boost)
Yes
Intel® Boot Guard
Yes
Intel® OS Guard
Yes
Intel® Secure Key
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel 64
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Operational conditions
Maximum operating temperature
105 °C
general_information_attribute_container_name
Product series
Ultra 5
attribute_product_family_name
Core
Packaging data
Package type
Tray
Technical details
OpenCL version
3.0
Status
Launched
Launch date
Q1'25
Other features
L2 cache
22528 KB
Maximum internal memory
192 GB
Graphics output
DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
