Maximum internal memory supported by processor: 192 GB DDR5-SDRAM
On-board graphics card Intel Graphics
Box
Boxed Intel Core Ultra 5 processor 225 (20M Cache, up to 4.90 GHz) FCLGA18W
The latest Intel® Core™ Ultra processors (Series 2) enable you to use the most AI experiences across desktop, mobile and edge—making everything you do easier, faster, and better.
Processor
Processor ARK ID
241070
Processor codename
Arrow Lake
Maximum number of DMI lanes
8
AI software frameworks supported by CPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum turbo power
121 W
Processor base power
65 W
Processor cache type
Smart Cache
Processor cache
20 MB
Efficient-core base frequency
2.7 GHz
Efficient-core boost frequency
4.4 GHz
Performance-core base frequency
3.3 GHz
Performance-core boost frequency
4.9 GHz
Processor boost frequency
4.9 GHz
Efficient cores
4
Performance cores
6
Processor operating modes
64-bit
Processor threads
10
Processor socket
LGA 1851 (Socket V1)
Processor cores
10
Processor model
225
Processor generation
Intel Core Ultra (Series 2)
Processor family
Intel Core Ultra 5
Processor manufacturer
Intel
Neural processor unit (NPU)
GPU performance up to
4 TOPs
NPU performance up to
13 TOPs
Total processor performance up to
23 TOPs
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Windows Studio effects support
Yes
Sparsity support
Yes
Neural processor unit (NPU)
Intel AI Boost
Memory
Memory channels
Dual-channel
Memory clock speeds supported by processor
6400 MHz
Memory types supported by processor
DDR5-SDRAM
Maximum internal memory supported by processor
192 GB
Graphics
Xe-cores
2
Discrete graphics card model
Not available
On-board graphics card ID
0x7D67
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)
