iiyama TW2223AS-B3P Signage Display Interactive flat panel 54.6 cm (21.5") Wi-Fi 450 cd/m² Full HD Black Touchscreen Built-in processor Android 24/7
iiyama TW2223AS-B3P Signage Display Interactive flat panel 54.6 cm (21.5") Wi-Fi 450 cd/m² Full HD Black Touchscreen Built-in processor Android 24/7
SKU:TW2223AS-B3P
Low stock: 3 left
Couldn't load pickup availability
Delivery & lead times
Delivery & lead times
Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.
Buying 5 or more? Volume pricing
Buying 5 or more? Volume pricing
We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.
Returns & warranty
Returns & warranty
See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.
- Indoor Interactive flat panel Black
- 54.6 cm (21.5") 1920 x 1080 pixels 450 cd/m²
- Touchscreen 14 ms
- Ethernet LAN Wi-Fi
- Built-in speaker(s) 4 W
The ProLite TW2223AS-B3P interactive Touchpanel-PC is a perfect choice for high-use environments. The IPS panel, integrated in a slim and elegant bezel, delivers both excellent colour performance with wide viewing angles and noticeably sharper images. The In-cell 10tp PCAP touch technology ensures a fluid and natural touch experience. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Thanks to the pre-installed Android 14 operating system, it is possible to easily customize the monitor by installing applications directly to it. In combination with the 32GB storage, Wi-Fi connection, LAN (RJ45) and Bluetooth connectors, it makes the monitor especially suited for POS systems or information points in retail shops to educate customers about your products, as well as virtually limitless smart home applications. Thanks to Power over Ethernet (PoE), both power and data are delivered through a single cable, simplifying installation and reducing additional cables. Additionally, it integrates effortlessly with iiSignage2 , iiyama’s Content Management System (CMS), giving you full control over your messages and advertising.
| Display | |
|---|---|
| Display diagonal | 54.6 cm (21.5") |
| Panel type | IPS |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 450 cd/m² |
| HD type | Full HD |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
| Native aspect ratio | 16:9 |
| Response time | 14 ms |
| Contrast ratio (typical) | 1500:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.248 x 0.248 mm |
| Active display area (W x H) | 476.1 x 267.8 mm |
| Display diagonal (metric) | 54.6 cm |
| Glass thickness | 2.9 mm |
| Colour depth | 8 bit |
| Surface hardness | 6H |
| Horizontal scan range | 31 - 83 kHz |
| Ports & interfaces | |
|---|---|
| DVI port | No |
| USB port | Yes |
| USB ports quantity | 3 |
| USB connector type | USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi standards | Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b |
| Wi-Fi | Yes |
| Audio (L/R) in | 2 |
| Microphone in | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Audio | |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 4 W |
| Design | |
|---|---|
| Product design | Interactive flat panel |
| Product colour | Black |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Bezel colour | Black |
| Performance | |
|---|---|
| Purpose | Universal |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| Mean time between failures (MTBF) | 50000 h |
| Power | |
|---|---|
| Power consumption (typical) | 15.4 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Power over Ethernet (PoE) | Yes |
| Computer system | |
|---|---|
| Computer system | Yes |
| Built-in processor | Yes |
| Processor family | ARM Rockchip |
| Processor model | Rockchip RK3576 |
| Internal memory | 4 GB |
| Internal storage capacity | 32 GB |
| Operating system installed | Android |
| Operating system version | 14 |
| Google applications | Google Chrome, Gmail, Google Calendar |
| Weight & dimensions | |
|---|---|
| Display width | 504.5 mm |
| Display depth | 32 mm |
| Display height | 302 mm |
| Display weight | 3.64 kg |
| Width | 504.5 mm |
| Depth | 32 mm |
| Height | 302 mm |
| Weight | 3.64 kg |
| Width (with stand) | 504.5 mm |
| Depth (with stand) | 32 mm |
| Height (with stand) | 302 mm |
| Weight (with stand) | 3.64 kg |
| Packaging data | |
|---|---|
| Package width | 580 mm |
| Package depth | 375 mm |
| Package height | 126 mm |
| Package weight | 6 kg |
| Packaging content | |
|---|---|
| Cables included | AC |
| Technical details | |
|---|---|
| Compliance certificates | CE, EAC, REACH, RoHS, UKCA, WEEE |
| Sustainability certificates | ErP |
| User controls | Power switch, volume/ button +, volume/ button - |
| Other features | |
|---|---|
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Brightness | 450 cd/m² |
| AC adapter included | Yes |
| Viewable size, vertical | 26.8 cm |
| Viewable size, horizontal | 47.6 cm |
| Cable management | Yes |
| Power supply type | External |
| Bluetooth version | 5.3 |
| Bluetooth | Yes |
| Quick start guide | Yes |
