Hewlett Packard Enterprise

HPE ProLiant MicroServer Gen10+ v2 server Ultra Micro Tower Intel® Xeon® E-2314 2.8 GHz 16 GB DDR4-SDRAM 180 W

HPE ProLiant MicroServer Gen10+ v2 server Ultra Micro Tower Intel® Xeon® E-2314 2.8 GHz 16 GB DDR4-SDRAM 180 W

Regular price £1,350.26 GBP
Regular price Sale price £1,350.26 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:P54649-421

Low stock: 2 left

  • Intel® Xeon® E-2314 2.8 GHz
  • 16 GB 3200 MHz DDR4-SDRAM 1 x 16
  • Ultra Micro Tower 180 W
Intel Xeon E-2314 (2.8GHz, 8MB), 16GB (1 x 16GB) DDR4, 4LFF-NHP, Intel VROC SATA SW RAID, 1x 180W External PS

Are you a small office, home office, or small business with branch offices looking to build a customized solution for your office?

The HPE ProLiant MicroServer Gen10 Plus v2 server delivers an affordable compact yet powerful entry-level server that you can customize for on-premises or for hybrid cloud possibilities. It has the same compact form factor as the previous version and can be placed flat or vertically depending on your space. Intel® Xeon® E Processor and Intel® Pentium® Gold Processor Series build compute performance as well as security and remote management into the server with HPE iLO Silicon Root of Trust from HPE iLO. Along with other enhancements such as 4 x 1GbE onboard NICs and USB 3.2 Type-A Gen2, there is nothing micro about the HPE ProLiant MicroServer Gen10 Plus v2 server.

Features

More Micro and Versatile, Yet More Powerful
- The HPE ProLiant MicroServer Gen10 Plus v2 server measures 4.68 in (11.89 cm) and can be placed either horizontally or vertically to fit different customer workspaces.
- Powered by up to four cores in the Intel® Xeon® E Processor and up to 64 GB of 3200 MT/s DDR4 ECC UDIMM, it delivers better performance for small business applications.
- HPE iLO 5 standard and essential functionality (optional), remote monitoring, restore, and maintenance are now available.1 It is supported by installing an optional iLO Enablement kit, which includes an HPE iLO dedicated port. HPE InfoSight and HPE OneView are also supported.
- Four embedded network ports provide the networking needs of small business customers. Optional 1GbE and 10GbE BASE-T and SFP+ standup option cards are supported for those who require more.

Security Innovations
- The HPE ProLiant MicroServer Gen10 Plus server v2 server is one of our industry-standard servers with major firmware anchored directly into the silicon security protection built-in across the server lifecycle, starting with Silicon Root of Trust.
- Secure Recovery allows server firmware to roll back to the last, known-good state or factory settings after detection of compromised code.
- Additional security options are available with Trusted Platform Module (TPM) to prevent unauthorized access to the server and reliably store artifacts used to authenticate the server.

Industry-Leading Services and Ease of Deployment
- The HPE ProLiant MicroServer Gen10 Plus v2 server comes with an available complete set of services from HPE Pointnext Services, delivering confidence, reducing risk, and helping you realize agility and stability.
- HPE Pointnext Services simplifies all stages of the IT journey. Advisory and Professional Services understand customer challenges and design an enhanced solution. Professional Services enables rapid deployment of solutions and Operational Services provides ongoing support.
- Services provided under Operational Services include: HPE GreenLake Flex Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services, and multi-vendor coverage.
- HPE IT investment solutions help you transform into a digital business with IT economics that aligns with your business goals.
- Make server deployment easy with custom RAID and setup with HPE Intelligent Provisioning and auto-intelligent RAID with HPE Rapid Setup.

Processor
Idle States Yes
Execute Disable Bit Yes
Number of processors installed 1
Motherboard chipset Intel C252
Processor cache 8 MB
Processor cores 4
Processor boost frequency 4.5 GHz
Processor frequency 2.8 GHz
Processor model E-2314
Processor family Intel® Xeon®
Processor manufacturer Intel
Memory
Maximum internal memory 64 GB
Memory clock speed 3200 MHz
Memory layout (slots x size) 1 x 16 GB
Memory slots 2x DIMM
Internal memory type DDR4-SDRAM
Internal memory 16 GB
Storage
Optical drive type No
Hot-Plug support No
RAID levels 0, 1, 5, 10
RAID support Yes
Supported HDD sizes 3.5"
Number of HDDs supported 4
HDD interface SATA
Maximum storage capacity 16 TB
Network
Ethernet interface type Gigabit Ethernet
LAN controller Intel® I350-AM4
Ethernet LAN Yes
Ports & interfaces
DisplayPorts quantity 1
VGA (D-Sub) ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
USB 2.0 ports quantity 1
Ethernet LAN (RJ-45) ports 4
Design
Chassis type Ultra Micro Tower
Performance
Remote administration iLO 5 ASIC
Software
Compatible operating systems Microsoft Windows Server 2019: Essentials, Standard, Datacenter, Hyper-VMicrosoft Windows Server 2022: Essentials, Standard, DatacenterRed Hat Enterprise Linux (RHEL): 8.4 (64 bit, includes KVM)VMware vSphere: 7.0 U3
Operating system installed No
Processor special features
Enhanced Intel SpeedStep Technology Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Trusted Execution Technology Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
CPU configuration (max) 1
Intel Software Guard Extensions (Intel SGX) Yes
Power
Power supply 180 W
Redundant power supply (RPS) support No
general_information_attribute_container_name
attribute_product_family_name ProLiant
Weight & dimensions
Weight 4.23 kg
Depth 245 mm
Height 118.9 mm
Width 245 mm
