Read details more clearly and see high-contrast colour with new high-definition HP printheads. HP Pixel Control enables smooth gradients, and the integrated vertical trimmer streamlines finishing.[3] Handle complex files and secure your printers/data.
Dynamic security enabled printer Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges.
PDF 1.7, PostScript 3, TIFF, HP-GL/2, HP-RTL, JPEG, CALS G4
Number of print cartridges
6
Print resolution colour
2400 x 1200 DPI
Maximum resolution
2400 x 1200 DPI
Colour
Yes
Print technology
Inkjet
Copying
Copying
No
Scanning
Scanning
No
Paper handling
Roll widths supported
279 - 610mm
Media width (sheets)
610 mm
Maximum roll diameter
13.5 cm
Maximum roll width
61 cm
Media thickness
0.8 mm
Cut sheets
Yes
ISO A-series sizes (A0...A9)
A1, A2, A3, A4
Paper tray media types
Banner, Bond paper, Coated paper, Photo paper
Maximum print size
A1 (594 x 841 mm)
Ports & interfaces
Mobile printing technologies
HP ePrint
RJ-45 ports quantity
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Wi-Fi Direct
Yes
USB 2.0 ports quantity
1
USB connector
USB Type-A
USB port
Yes
Ethernet LAN
Yes
Performance
Certification
Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS)
Sound pressure level (printing)
42 dB
Sound power level (standby)
33 dB
Storage media
HDD
Internal storage capacity
500 GB
Internal memory
4096 MB
Display
LED
Built-in display
Yes
Product colour
Grey
Brand-specific features
HP Care Pack
Yes
HP Web Jetadmin
Yes
HP ePrint
Yes
Power
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Power consumption (typical)
100 W
Power consumption (off)
0.1 W
Power consumption (sleep)
6.5 W
Operational conditions
Storage temperature (T-T)
-25 - 55 °C
Operating relative humidity (H-H)
20 - 80%
Operating temperature (T-T)
5 - 40 °C
System requirements
Windows operating systems supported
Yes
Mac operating systems supported
Yes
Sustainability
Sustainability compliance
Yes
Sustainability certificates
ENERGY STAR, Forest Stewardship Council (FSC), Post-Consumer Recycled Plastic
Sustainable technologies and materials
30% post-consumer recycled plastic; Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; Highest WIR Print Permanence Ratings in the Industry; Compatible with FSC®-certified HP large format printing materials and HP Recycled Satin Canvas, and a range of recyclable HP media with a take-back program; ENERGY STAR® certified; EPEAT® registered
Weight & dimensions
Weight
66 kg
Height
998 mm
Depth
695 mm
Width
1293 mm
Packaging data
Bundled software
HP Click printing software, HP PrintOS, HP Web Jetadmin, HP DesignJet Utility including HP Color Center, HP Partner Link, HP JetAdvantage Security Manager (optional), HP SmartStream (optional), HP SmartTracker (optional)
Drivers included
Yes
Quick start guide
Yes
Cartridge(s) included
Yes
Package weight
97 kg
Package height
718 mm
Package depth
766 mm
Package width
1440 mm
general_information_attribute_container_name
attribute_product_family_name
Designjet
Other features
Electromagnetic compatibility
EU (EMC Directive), South Africa (SABS)
Safety
EU (LVD and EN 60950-1 compliant); Russia, Belarus, Kazakhstan (EAC)
