Ernitec SR-1X54R-HW-WS server 500 GB Rack 6357P 32 GB DDR5-SDRAM 300 W Windows Server 2025

Ernitec SR-1X54R-HW-WS server 500 GB Rack 6357P 32 GB DDR5-SDRAM 300 W Windows Server 2025

SR-1X54R-HW-WS

£11,319.00 GBP£9,432.50 GBP
£0.00 GBP £11,319.00 GBP£9,432.50 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

Low stock: 4 left

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • Short depth: 54CM
  • Xeon 6357P CPU - 3.0-5.4GHz - 8C/16T
  • Dual 1GbE NICs + dedicated IPMI NIC
  • 2x 500GB SSD RAID1 OS drive
  • Windows Server 2025 Standard Preinstalled.
  • Support for up to 4x 3.5" hot swap HDDs with HW RAID support
  • Rails included
  • To reduce waste only Euro CEE 7 to C13 power cables are included.
  • Suitable for up to 50 4MP cameras @25 FPS
1U 4 Bay Server: Xeon 6357P, 32GB RAM, 2x500GB, 9361 RAID, 2x1GbE, IPMI, TPM, dual 300W PSU, Windows Server 2025 STD – Suitable for up to 50 4MP cameras @25 FPS

1U 4 Bay Server - Suitable for up to 50 4MP cameras @25 FPS
This compact and versatile 1U server features an Intel Xeon 6357P processor, 32GB RAM, dual 500GB OS SSDs. Configured with a 9361 RAID controller for data redundancy and performance on the 4 front drive bays, and dual 1GbE network ports. It includes IPMI for remote management, TPM for enhanced security, and dual 300W redundant power supplies. Pre-installed with Windows Server 2025 STD, it's ideal for secure, high-availability deployments in space-constrained environments.

Processor
Processor manufacturer Intel
Processor model 6357P
Performance-core base frequency 3 GHz
Performance-core Max Turbo Frequency 5.4 GHz
Performance cores 8
Processor cores 8
Processor threads 16
Processor socket LGA 1700
Cache internal 24 MB
Memory
Internal memory 32 GB
Internal memory type DDR5-SDRAM
Memory layout (slots x size) 2 x 16 GB
Memory data transfer rate 4400 MT/s
Maximum internal memory 128 GB
Storage
Total storage capacity 500 GB
HDD capacity 500 GB
Number of HDDs supported 4
Supported HDD sizes 2.5"
Number of SSDs installed 2
SSD capacity 500 GB
SSD size 2.5"
Hot-swap Yes
Supported storage drive interfaces M.2
Graphics
On-board graphics card Yes
On-board graphics card model Aspeed AST2600
On-board graphics card 4K support Yes
Number of displays supported (on-board graphics) 1
Network
Number of LAN controllers 2
LAN controller Intel® I210-AT
Ethernet interface type Gigabit Ethernet
Ethernet LAN Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
USB 2.0 ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 4
VGA (D-Sub) ports quantity 1
Design
Chassis type Rack
Cooling type Active
Product colour Black
Rack rails Yes
Rack mounting Yes
Performance
Trusted Platform Module (TPM) version 2.0
Trusted Platform Module (TPM) Yes
Software
Operating system installed Windows Server 2025
Operating system language English
Power
Power supply 300 W
Number of main power supplies 2
Power consumption (typical) 120 W
Weight & dimensions
Width 580 mm
Height 137 mm
Depth 680 mm
Weight 8 kg
Package width 580 mm
Package depth 680 mm
Package height 137 mm
Package weight 9 kg
Technical details
Supported RAID configuration 0, 1, 5, 6, 10
Other features
Warranty period 3 year(s)
Integrated LAN Yes
Integrated BMC with IPMI Yes
Dimensions (WxDxH) 430 x 537.55 x 43.3 mm
RAID controller type Hardware (Storage drives)
