Ernitec ELECTRA-U06-1GB network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE)

• 4*1Gbps PoE ports+1*1Gbps uplink RJ45 port+1*1Gbps SFP port
• PoE ports automatically open PoE watchdog mode in Extend mode
• Working Temperature from -40~75°C
• 4PIN industrial terminal+DC2.1 input interface, DC48-55V wide voltage input
• Support VLAN, Genius, and Extend modes
• Support rail and wall mounting installation
• 5 Year Warranty

The Ernitec 6-port 1000Mbps Intelligent Industrial PoE Switch is designed for high-performance and reliability in industrial settings. Here are some key features:
Gigabit Ethernet Ports: Six 10/100/1000 Mbps PoE ports for fast and efficient data transfer.
PoE Capability: Supports Power over Ethernet (PoE) to power devices like IP cameras and wireless access points directly through the Ethernet cables.
Industrial-Grade Design: Built to withstand harsh environments with a rugged housing and wide operating temperature range.
Flexible Network Expansion: Two Gigabit SFP uplink ports for easy network expansion.
This switch is ideal for applications requiring robust and reliable network connectivity in challenging environments.
4 x 1000Mbps PoE RJ45 ports
1 x 1000Mbps uplink RJ45 port
1 x 1000Mbps uplink SFP port
Ports 1-4 support standard PoE power supply and comply with IEEE 802.3af/at international standards.
Port 1 support 90W BT
IEEE802.3 (Ethernet)
IEEE802.3u (Fast Ethernet)
IEEE802.3ab (Gigabit Ethernet)
IEEE802.3z (Gigabit Ethernet Fibre Standards)
IEEE802.3x (Flow Control)
Operates in temperatures ranging from -40°C to 75°C.
Features a 4-pin industrial terminal and DC2.1 input interface, with a wide voltage input of DC48-55V.
Supports VLAN, Genius, and Extend modes.
Suitable for both rail and wall mounting installations.
