Ernitec ELECTRA-PWR-120-24 power supply unit 120 W Blue

Ernitec ELECTRA-PWR-120-24 power supply unit 120 W Blue

ELECTRA-PWR-120-24

£78.66 GBP£65.55 GBP
£0.00 GBP £78.66 GBP£65.55 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

20 in stock

Delivery & lead times

Some products ship directly from our suppliers and can have longer lead times than stock held in the UK. If you need a delivery date, please contact us before ordering. See our shipping policy.

Buying 5 or more? Volume pricing

We offer volume pricing, business accounts and quotations for organisations. Request a quote or call 01344 963637.

Returns & warranty

See our refund policy. Manufacturer warranty terms vary by product - contact us if you need warranty details before you buy.

  • Universal AC input for full operation
  • Protection features: short circuit, overload, over voltage and over temperature
  • Cooling by free air convection
  • DIN rail TS-35/7.5 or 15 installation
  • UL 508 (industrial control equipment) approved
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • 100% full load burn-in test
DC Single Output Industrial DIN Rail Power Supply Units - 24V

Compact Size with more Practicability and Convenience
Ernitec has released PWR series for industrial Ethernet devices specially designed for the harsh working environment where sometimes it is hard to find suitable DC voltage power source.
The PWR series offered includes DC single output industrial DIN rail power supply units which accept universal 100-240 AC input voltage or DC input and provide 24V DC power output with various watt values.
They are designed in compact size and can be installed on DIN rail TS-35 / 7.5 or 15.
It is an ideal and convenient DC power feeding solution for industrial equipment under heavy Industrial environments.
Stable Performance under Difficult Environments
The DC Single Output Industrial DIN Rail Power Supply Units provides various models with short circuit/overload/over voltage and over temperature protections for the stable operation of Industrial Ethernet equipment.
As they adopt the free air convection cooling system, they are able to operate under the temperature ranging from -20 to 70 degrees C (maximum). Thus, the DC single output industrial DIN rail power supply units can be placed in almost any difficult environments.
Universal AC input / full range - AC input range selectable by switch - Protection: short circuit / overload / over voltage / over temperature - Cooling by free air convection - For installation on DIN rail TS-35/7.5 or 15 - UL 508 (industrial control equipment) approved - LED indicator for power on - 100% full load burn-in test - Fixed switching frequency at 55KHz

Power
Total power 120 W
AC input voltage 100 - 240 V
Input current 2.25 A
Power protection features Over voltage
Performance
Safety Ul508, TUV EN60950-1
Design
Product colour Blue
Cooling type Passive
On/off switch No
Operational conditions
Operating temperature (T-T) -20 - 70 °C
Storage temperature (T-T) -40 - 85 °C
Operating relative humidity (H-H) 20 - 95%
Storage relative humidity (H-H) 10 - 95%
Weight & dimensions
Width 315 mm
Depth 340 mm
Height 310 mm
Weight 510 g
Packaging data
Package width 315 mm
Package depth 340 mm
Package height 310 mm
Package weight 610 g
Other features
Output power description 120W
