Epson WorkForce DS-970
Epson WorkForce DS-970
Couldn't load pickup availability
SKU:B11B251401BY
14 in stock
- High-speed scanning: 100-page ADF and 85ppm (170ipm) scanning speed
- Low intervention: Active Separation Roller system to prevent double feeding
- Built-in protection: Ultrasonic and paper protection sensors to detect processing errors
- Optional flatbed scanner: Choose from the conversion kit, or link to DS-5500 (A4) or DS-50000 (A3)
High-volume sheet-fed scanner
Create a better business environment with the support of a global leader in document scanning. When the goal is getting documents to the right place as fast as possible, trust in the WorkForce DS-970 - Epson's fastest scanner. High performance matched with an endurance with easy-to-use features that put you in control of your documents.
Ultimate performance
Epsons' fastest A4 document scanner offers class-leading performance{s1. With a 100-page ADF, 85ppm/170ipm scanning speed and continuous scanning with its automatic feed mode, the WorkForce DS-970 gets through large jobs quickly and efficiently. Scroll through pre-defined jobs easily using the intuituve panel and get your documents to the right place in just a few presses of a button. TWAIN, WIA and ISIS drivers are available for enhanced compatibility with document management systems.
Efficient document processing
Stay in control of the document process with a scanner capable of scanning a wide range of media from 27gsm to 413gsm and a long paper scanning mode up to 6096mm. Slow mode decreases document friction by reducing the speed of the rollers, making it easier to capture fragile or damaged documents, without increasing file sizes. The Active Separation Roller System prevent document double feeds, ensuring that every piece of paper gets scanned, and the Double Feed Detection Skip (DFDS) function means you can scan difficult media like envelopes or documents with post-it notes.
| Scanning | |
|---|---|
| Maximum scan size | 215.9 x 6096 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Input colour depth | 30 bit |
| Output colour depth | 24 bit |
| Output monochrome depth | 1 bit |
| ADF scan speed (b/w, A4) | 85 ppm |
| ADF scan speed (colour, A4) | 170 ppm |
| Black/white scanning colour modes | Monochrome |
| Design | |
|---|---|
| Scanner type | Sheet-fed scanner |
| Built-in display | Yes |
| Product colour | Black, White |
| Display | LCD |
| Display diagonal | 3.71 cm (1.46") |
| Colour display | Yes |
| Performance | |
|---|---|
| Sensor type | CIS |
| Light source | LED |
| Scan file formats | BMP, JPEG, PDF, PNG, TIFF |
| Daily duty cycle (max) | 14000 pages |
| Scan to | E-mail, FTP, Print |
| Ultrasonic sensor | Yes |
| Scan drivers | TWAIN, SANE, WIA, ICA, ISIS |
| Scanning noise level | 55 dB |
| Input capacity | |
|---|---|
| Standard input capacity | 100 sheets |
| Auto document feeder (ADF) input capacity | 100 sheets |
| Paper handling | |
|---|---|
| Maximum ISO A-series paper size | A3 |
| Scanning media types supported | Business Card, Plastic Card |
| ISO B-series sizes (B0...B9) | B4, B5, B6 |
| ISO A-series sizes (A0...A9) | A4, A5, A6 |
| Legal | Yes |
| Letter | Yes |
| Auto Document Feeder (ADF) media weight | 27 - 413 g/m² |
| Maximum scan area (ADF) | 50.8 x 50.8 mm |
| Ports & interfaces | |
|---|---|
| USB port | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1) |
| Power | |
|---|---|
| Power consumption (typical) | 20 W |
| Power supply type | AC |
| Power consumption (standby) | 8.5 W |
| Power consumption (off) | 0.1 W |
| AC input frequency | 50 - 60 Hz |
| Sleep mode | Yes |
| Input voltage | 100-240 V |
| Power consumption (sleep) | 1.4 W |
| general_information_attribute_container_name | |
|---|---|
| attribute_product_family_name | WorkForce |
| Network | |
|---|---|
| Supported network protocols | TCP/IP, DHCP, DNS, SNMP, SLP |
| Features | |
|---|---|
| Country of origin | Indonesia |
| Packaging data | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 260 mm |
| Package depth | 363 mm |
| Package height | 310 mm |
| Package weight | 4.6 kg |
| System requirements | |
|---|---|
| Compatible operating systems | Mac OS 10.6+, Windows 10, Windows 10 (32/64 bit), Windows 11, Windows 7, Windows 8, Windows 8.1, Windows Server 2003, Windows Server 2008 (32/64bit), Windows Server 2012 R2, Windows Vista, Windows XP SP3 |
| Server operating systems supported | Windows Server 2003, Windows Server 2008, Windows Server 2012 R2 |
| Mac operating systems supported | Mac OS X 10.6 Snow Leopard |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | 25 - 60 °C |
| Operating relative humidity (H-H) | 15 - 80% |
| Storage relative humidity (H-H) | 15 - 85% |
| Weight & dimensions | |
|---|---|
| Width | 296 mm |
| Depth | 169 mm |
| Height | 167 mm |
| Weight | 3.6 kg |
| Packaging content | |
|---|---|
| Manual | Yes |
| Warranty card | Yes |
| AC adapter included | Yes |
| Cables included | AC, USB |
| Drivers included | Yes |
| Bundled software | Document Capture Pro, Epson Device Admin, Epson Scan 2 |
| Other features | |
|---|---|
| Interface | USB 3.2 Gen 1x1 |
| Image formats supported | BMP, JPEG, TIFF, MTIFF, PNG |
| Linear scan speed (metric) | Monochrome:85 pages/min - Color:85 pages/min measured with Size: A4 , Resolution: 200 / 300 dpi, Monochrome:170 image/min - Color:170 image/min measured with Size: A4 , Resolution: 200 / 300 dpi |
| Scanner features | RGB colour dropout, Advanced Colour Dropout / Enhance, Skip blank page, A3 stitching, Punch holes removal, Advanced editing, Pre-defined scanning settings, Automatic de-skew, Automatic multi-document recognition, Dual Image Output (Windows only), Auto-rotation, Text enhancement, Edge fill, Barcode Recognition, Manual / Automatic Job Separation, Scan to Cloud Storage |
| Printer features | RGB colour dropout, Advanced Colour Dropout / Enhance, Skip blank page, A3 stitching, Punch holes removal, Advanced editing, Pre-defined scanning settings, Automatic de-skew, Automatic multi-document recognition, Dual Image Output (Windows only), Auto-rotation, Text enhancement, Edge fill, Barcode Recognition, Manual / Automatic Job Separation, Scan to Cloud Storage |
| Output resolutions | 1200 DPI |
| Box contents | AC adapter, Driver and utilities, Main unit, Power cable, Setup guide, USB cable, Warranty card |
| Technical details | |
|---|---|
| Data compression | TIFF Compression (JPEG(7) , CITT G4, LZW), PDF Compression, JPEG compression |
| Logistics data | |
|---|---|
| Products per pallet | 48 pc(s) |
| Products per pallet (UK) | 60 pc(s) |
| Products per pallet layer (UK) | 10 pc(s) |
| Products per pallet layer | 8 pc(s) |
| Harmonized System (HS) code | 84716070 |
