Reliable hardware: Backed by our tried and trusted build quality
High performance: Max print speed 500mm/s
Connectivity and interface options: USB, Ethernet, USB Host as standard; serial, PoweredUSB, options
Backwards compatible: Fully compatible with the existing T88V and T88VI software
Reduced environmental impacts: Low power consumption, support for Phenol-free paper
Epson TM-T88VII (132): USB, Eth, PowerUSB, Buzz, Black
High-speed receipt printer The TM-T88VII is our new high-performance receipt printer range. It features a range of design, connectivity and usability improvements and enhancements to improve the user experience.
Reliable and high-performance Avoid downtime by choosing proven, reliable hardware from the market leader{s1. Fast print speeds of 500mm/s and high-quality, printed legible receipts will ensure happy customers.
Backwards compatible The TM-T88VII is fully compatible with the existing T88V and T88VI software so there are no expensive costs associated with changing business infrastructure. The printer also has same footprint as previous models, meaning no additional costs of having to change the counters/tills.
Eco-conscious The TM-T88VII demonstrates reduced environmental impacts, with lower noise level, lower power consumption and smaller, more efficient power supply. The printer is now compatible with more eco-friendly, Phenol-free paper.
Printing
Print technology
Thermal
Type
POS printer
Maximum resolution
180 x 180 DPI
Print speed
500 mm/sec
Character size
1.41 x 3.39 mm
Printing characters
Text, Graphic, Barcode, 2D barcode
Character sets
ANK
Paper handling
Printing media thickness
48 - 80 µm
Media thickness
48 - 80 mm
Supported paper width
80 mm
Maximum roll diameter
8.3 cm
Ports & interfaces
Connectivity technology
Wired & Wireless
USB port
Yes
USB connector
USB Type-A / USB Type-B
Near Field Communication (NFC)
Yes
Optional connectivity
Wireless LAN
Network
Ethernet LAN
Yes
Features
Sound pressure level (standby)
52 dB
Sound pressure level (printing)
52 dB
Mean time between failures (MTBF)
360000 h
Autocutter durability
3 million cuts
Paper save function
Yes
Wall mountable
Yes
Mounting position
Horizontal/Vertical
Print head life
200 km
Country of origin
Philippines
Built-in sensors details
Paper End Sensor, Paper Near End Sensor, Cover Open Sensor, Receipt paper sensor
Certification
CE
Design
Product colour
Black
Power
Power source type
USB
Power consumption (printing)
27.9 W
AC input voltage
24 V
Power consumption (standby)
1.4 W
Power consumption
27900 mA
Operational conditions
Operating temperature (T-T)
5 - 45 °C
Storage relative humidity (H-H)
10 - 90%
Operating relative humidity (H-H)
10 - 90%
Storage temperature (T-T)
-10 - 50 °C
System requirements
Pre-installed software
Server Direct Print, ePOS-Device, ePOS-Display, ePOS-Print
