Epson EB-L720U
Epson EB-L720U
Couldn't load pickup availability
SKU:V11HA44040
Low stock: 1 left
- High brightness, scalable size: Provides 7,000 lumens high-brightness display at up to 500"
- Premium display features: Full HD, 4K support, edge-blending and geometric correction
- Unrestricted viewing: Free from pixilation, glare, fingerprints and a central bevel
- Social distancing support: Scalable display meets the needs of every audience configuration
- Plug, click and collaborate: Collaborate using Epson’s wireless presentation system - ELPWP10
WUXGA laser display
The EB-L720U delivers exceptional image quality, focussing on professional content delivery and display performance. Designed around ease of use, up to a 500" display size, affordability and sustainability, it's the ideal imaging solution for today's professional world.
Featuring a powerful 7,000 lumens high-brightness capability, along with Full HD, WUXGA, 16:6 wide screen, support for 4K input and detail enhancement technology, it gives users brighter, more vivid displays of up to 500”.
Providing more premium features than you would typically expect to find in this display class, the EB-L720U delivers edge-blending and rich geometric correction to achieve one seamless large-format display. And for multimedia content, you can playback content without any lagging, and create playlists and set schedules directly from USB memory, all thanks to H.264 advanced video coding and the Epson Content Manager.
Flexibility is another hallmark of this display solution - a split-screen function allows two or four images from different sources to be combined in one large display; wired or optional wireless{s1 with support for Miracast{s1 makes connectivity simple and straightforward; and HDBaseT content can be shared and distributed without compromising on quality.
Thanks to the renowned market leading{s2 reliability of Epson laser displays, this fit and forget solution eliminates the need for regular maintenance. And for added confidence the EB-L720U comes with a standard 3-year warranty to provide lasting peace of mind.
| Projector | |
|---|---|
| Projector brightness | 7000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 2500000:1 |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 1270 - 12700 mm (50 - 500") |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 4900 ANSI lumens |
| Vertical scan range | 192 - 240 Hz |
| Keystone correction, horizontal | -30 - 30° |
| Matrix size | 1.7 cm (0.67") |
| Keystone correction, vertical | -30 - 30° |
| Light source | |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Lens system | |
|---|---|
| Focus | Manual |
| Focal length range | 20 - 31.8 mm |
| Aperture range (F-F) | 1.5 - 1.7 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Zoom ratio | 1.6:1 |
| Throw ratio | 1.35 - 2.20:1 |
| Offset | 27% |
| Video | |
|---|---|
| Full HD | Yes |
| Video processing | 10 bit |
| Video colour modes | Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 3 |
| HDMI ports quantity | 2 |
| HDMI connector type | Full-size |
| DVI port | No |
| HDBaseT port | Yes |
| USB 2.0 ports quantity | 1 |
| USB 2.0 Type-B ports quantity | 1 |
| Serial interface type | RS-232C |
| PC Audio in | Yes |
| PC Audio out | Yes |
| Network | |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
| Storage | |
|---|---|
| Card reader integrated | No |
| Features | |
|---|---|
| Interactive | No |
| Noise level | 39 dB |
| Noise level (economic mode) | 27 dB |
| Country of origin | China |
| Multimedia | |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
| Design | |
|---|---|
| Product type | Standard throw projector |
| Product colour | White |
| Placement | Ceiling, Desktop, Floor, Wall |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Display | |
|---|---|
| Built-in display | No |
| Power | |
|---|---|
| Power source | AC |
| Power consumption (typical) | 345 W |
| Power consumption (standby) | 0.3 W |
| Power consumption (economy mode) | 258 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Software | |
|---|---|
| Software support | via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
|---|---|
| Weight | 7.8 kg |
| Width | 440 mm |
| Depth | 122 mm |
| Height | 304 mm |
| Package width | 540 mm |
| Package depth | 530 mm |
| Package height | 210 mm |
| Package weight | 10.8 kg |
| Packaging content | |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| WLAN adapter included | Yes |
| Warranty card | Yes |
| Manual | Yes |
| Cables included | AC, HDMI |
| Bundled software | EasyMP Multi PC Projection |
| Technical details | |
|---|---|
| Sustainability certificates | TCO |
| USB display function | 3 in 1: Image / Mouse / Sound |
| Logistics data | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Pallet weight (UK) | 0 g |
| Pallet gross weight | 0 g |
| Products per pallet (UK) | 14 pc(s) |
| Products per pallet | 14 pc(s) |
| Harmonized System (HS) code | 85286200 |
