Bright HD-Ready WXGA display Optimise your presentation's potential with this bright WXGA projector that’s capable of producing a large and scalable screen size. Excessive downtime is a thing of the past with this reliable projector that can deliver years of use before a replacement lamp is required or the air filter needs attention. It has a range of connectivity solutions and is fuss free to set up.
Projector
Projector brightness
4200 ANSI lumens
Projection technology
3LCD
Projector native resolution
WXGA (1280x800)
Contrast ratio (typical)
16000:1
Native aspect ratio
16:10
Screen size compatibility
736.6 - 7112 mm (29 - 280")
Projection distance (wide)
0.9 - 8.5 m
Projection distance (tele)
1.4 - 13.7 m
Number of colours
1.07 billion colours
Projector brightness (economic mode)
2600 ANSI lumens
Vertical scan range
100 - 120 Hz
Keystone correction, horizontal
±30°
Matrix size
1.5 cm (0.59")
Keystone correction, vertical
±30°
Light source
Light source type
Lamp
Service life of light source
6500 h
Service life of light source (economic mode)
17000 h
Lamp type
UHE
Lamp power
230 W
Lens system
Focal length range
18.2 - 29.2 mm
Aperture range (F-F)
1.51 - 1.99
Zoom capability
Yes
Zoom type
Manual
Zoom ratio
1.6:1
Throw ratio
1.38 - 2.24:1
Video
Full HD
No
3D
No
Video processing
10 bit
Video colour modes
Blackboard, Cinema, Dynamic, Sports, sRGB
Ports & interfaces
VGA (D-Sub) ports quantity
2
HDMI ports quantity
2
Composite video in
1
DVI port
No
USB 2.0 ports quantity
1
USB 2.0 Type-B ports quantity
1
Serial interface type
RS-232C
Network
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Features
Noise level
37 dB
Noise level (economic mode)
28 dB
Country of origin
Philippines
Password protection
Yes
Multimedia
Built-in speaker(s)
Yes
RMS rated power
16 W
Design
Product type
Standard throw projector
Market positioning
Portable
Product colour
White
Placement
Ceiling, Desktop
Cable lock slot type
Kensington
Cable lock slot
Yes
Power
Power source
AC
Power consumption (typical)
327 W
Power consumption (standby)
0.3 W
Power consumption (economy mode)
225 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Software
Software support
via: AMX, Crestron (Network), Control4, Extron
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Storage temperature (T-T)
-10 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Storage relative humidity (H-H)
10 - 90%
Weight & dimensions
Weight
3.1 kg
Width
309 mm
Depth
282 mm
Height
90 mm
Package width
385 mm
Package depth
395 mm
Package height
175 mm
Package weight
4.68 kg
Packaging content
Remote control included
Yes
Batteries included
Yes
WLAN adapter included
Yes
Quick start guide
Yes
Cables included
AC, HDMI
Bundled software
EasyMP Multi PC Projection, Epson Projector Management
Technical details
Mobile app support
Yes
Other features
AV Mute Slide, Automatic keystone correction, Built-in speaker, CEC compatible, Direct Power on/off, Document Camera Compatible, Easy OSD pre-setting, Horizontal and vertical keystone correction, Network projection, OSD copy function, PC Free, Quick Corner, Split-Screen-Function, Wireless LAN capable, iProjecton set-up by scanning a code
USB display function
2 in 1: Image/ Sound
Logistics data
Quantity per pack
1 pc(s)
Pallet weight (UK)
0 g
Pallet gross weight
0 g
Products per pallet (UK)
72 pc(s)
Products per pallet
72 pc(s)
Harmonized System (HS) code
85286200
Other features
Interface
USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), VGA in (2x), VGA out, HDMI in (2x), Composite in, Jack plug out, Jack plug in (2x), Cinch audio out, Wireless LAN IEEE 802.11a/b/g/n/ac (optional)
Supported network protocols
PJLink
Security features
Kensington lock, Control panel lock, Security cable hole, Wireless LAN unit lock, Password protection
Option type
Air filter, Ceiling mount, Document camera, External Speaker, Safety wire set, Spare lamp, Suspension adapter, WP System - ELPWP20, Wireless LAN unit, Wireless transmitter - ELPWT01
Box contents
HDMI Cable, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User Manual (CD-ROM), Warranty document
