- Black
- 54.6 cm (21.5") 1920 x 1080 pixels LED 225 cd/m²
- Touchscreen 25 ms
21.5'', 16:9, 1920 x 1080, 240 nits, 25 msec, 3000:1, VGA, HDMI, 100-240VAC, 50-60Hz, 4 x Micro USB, OSD Timeout, OSD Language, 6.8 kg
2202L
Touchscreen MonitorThe Elo 02-Series of Touchscreen Monitors designed with seamless style across all sizes includes four options — a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint.
Brilliant Displays from 19 to 27-inches
The clear glass touchscreens with Elo's industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience.
Well-Suited for...
Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
Connect your Accessories
From a barcode scanner to an EMV, Elo's 02-Series Monitors are compatible with a large set of peripherals purpose-built for commercial applications.
Fingerprint Reader
The Biometric Fingerprint Reader can be attached to provide secure and quick login.
MSR
Elo offers the flexibility of integrating payment devices, including a Magtek 3-track encryptable MSR payment terminal.
Barcode Scanner
Enhance self-service checkout and price-checker applications by coupling a high-performance barcode scanner onto the Elo touchscreen.
NFC
The Near Field Communication (NFC) adapter can be integrated for easy mobile payments with just a touch of the phone.
Privacy Matters
Optional privacy screens can help provide a physical safeguard for private information or sensitive data from the view of others. Whether you are the employee or the customer, privacy matters.
One for You.
One for Your Customers.Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion.
Mount with Flexibility
Customers demand a seamless shopping experience from first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party VESA mounts, the touchscreens can be integrated with ease.
| Display |
|---|
| Supported graphics resolutions |
640 x 400, 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1366 x 768, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+) |
| Display diagonal (metric) |
54.61 cm |
| Display number of colours |
16.78 million colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Contrast ratio (typical) |
3000:1 |
| Response time |
25 ms |
| Native aspect ratio |
16:9 |
| Touchscreen technology |
Projected capacitive system |
| Touchscreen |
Yes |
| Display brightness |
225 cd/m² |
| Display resolution |
1920 x 1080 pixels |
| LED backlight |
Yes |
| Display technology |
LED |
| Display diagonal |
54.6 cm (21.5") |
| Ports & interfaces |
|---|
| HDMI ports quantity |
1 |
| Design |
|---|
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Screen shape |
Flat |
| Product colour |
Black |
| Performance |
|---|
| Mean time between failures (MTBF) |
50000 h |
| Number of OSD languages |
10 |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Russian |
| Weight & dimensions |
|---|
| Weight (with stand) |
6.8 kg |
| Height (with stand) |
383.8 mm |
| Depth (with stand) |
193.4 mm |
| Width (with stand) |
526.9 mm |
| Packaging data |
|---|
| Package weight |
10.8 kg |
| Package height |
477 mm |
| Package depth |
260 mm |
| Package width |
617 mm |
| Packaging content |
|---|
| Cables included |
AC, Audio (3.5mm), HDMI, USB, VGA |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
10 - 95% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating temperature (T-T) |
0 - 40 °C |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Features |
|---|
| Wall mountable |
Yes |
| Other features |
|---|
| Built-in camera |
No |
| Built-in microphone |
No |
| Power supply type |
AC |
| Quick start guide |
Yes |
| Aspect ratio |
16:9 |
| Display viewable area (HxV) |
467.06 x 267.78 mm |
| Weight (without stand) |
5.2 kg |
| Dimensions (W x D x H) with stand |
526.9 x 193.4 x 383.8 mm |
| Headphone outputs |
1 |
| Maximum refresh rate |
60 Hz |
| Micro-USB ports quantity |
4 |
