Snappy omnidirectional reading from contact to over 2.0 m / 6.5 ft
Datalogic’s new instinctive ‘frame’ aimer
Water and Particulate Sealing Rating: IP65 and IP67
10 million trigger hits
White light illumination
Datalogic’s 3GL™ (3 Green Lights) technology and loud beeper for good-read feedback
Datalogic’s Motionix™ motion-sensing technology
Ergonomic shape provides hours of tireless data collection for the user
Supports 1D, stacked and 2D codes, postal codes and image capture
EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI
1D/2D, 1280×800, RS232, 19 x 14 x 7.9 cm, 318 g
PowerScan PD9630-SR, Standard Range, RS-232 Kit (Kit includes Scanner and RS232 Cable CAB-549)
Ultra-rugged with new balanced ergonomics! The PowerScan family of bar code readers are the ultimate industrial handheld scanners designed and constructed to withstand the toughest environmental conditions. The PowerScan PD9630 imagers have an ultra-rugged design, an ergonomic shape with well-balanced weight to reduce operator stress during daily activities and an intuitive aiming system, allowing the highest first-pass reading rate while reducing unnatural wrist movement.
Three optic options to fulfill any customer need The PowerScan PD9630 area imagers are available in three different optics, to satisfy any customer need. The Standard Range optic is ideal for most of the applications requiring barcode reading at intuitive distance; the High Performance optic adds the capability to decode high density barcodes together with an increased depth of field on standard 1D/2D codes; the Document Capture model is thought for Wide Angle code reading and Document Capture applications.
The best feedback to the operator The PD9630 area imagers also feature Datalogic’s exclusive 3 Green Lights (3GL™) for superior good-read feedback together with a loud beeper and vibration. The ‘Green Spot’ technology directly on the code and dual Good Read LEDs increase visibility at any angle. All models have multi-interface capabilities featuring the most popular interfaces: RS-232, USB and offer an optional Ethernet for standard or industrial uses.
Datalogic’s Motionix™ motion-sensing technology detects the natural actions of the operator to automatically switch the scanner into the desired scanning mode (handheld or presentation scanning).
Scanning
Yaw reading angle
-52 - 52°
Pitch reading angle
-52 - 52°
Tilt reading angle
0 - 360°
Wavelength
630 nm
Light levels (direct sunlight)
0 - 100000 lx
Working distance
20 cm
Optical sensor resolution (W x H)
1280 x 800 pixels
Linear (1D) barcodes supported
China Post, Code 128, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported
Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Scanner type
1D/2D
Type
Handheld bar code reader
Ports & interfaces
Standard interfaces
RS-232
Connectivity technology
Wired
Performance
Vibration function
Yes
Print contrast
15%
Buzzer
Yes
LED indicators
Yes
Protection features
Dirt resistant, Drop proof, Dust resistant, Electrostatic Discharge (ESD) protection, Water resistant
