Datalogic

Datalogic Magellan 1500i Fixed bar code reader 2D LED Black

Datalogic Magellan 1500i Fixed bar code reader 2D LED Black

Regular price £300.44 GBP
Regular price Sale price £300.44 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:MG1501-10211-0200

65 in stock

  • Fixed bar code reader Plastic Black
  • Scanner type: 2D Sensor type: LED
  • Aztec Code, Data Matrix, MaxiCode, QR Code
  • 1280 x 800 pixels
  • Tilt reading angle: 0 - 360°
  • Wired Standard interfaces: USB
  • Power source type: USB
Magellan 1500i, Black, Std Configuration, 2D, Tilting Stand with Magnetic Base, USB A Cable

Magellan 1500i
The Magellan 1500i is a high performance presentation scanner from Datalogic for a variety of applications including retail point of sale, pharmacy and customer service. The Magellan 1500i scanner provides outstanding performance on 1D and 2D bar codes from a variety of printed and mobile sources. The addition of Digimarc® Barcodes watermark decoding makes this a uniquely capable scanner in the presentation category.

Datalogic’s Magellan 1500i scanner is a high performance presentation scanner for a variety of applications including retail point of sale, pharmacy and customer service. The Magellan 1500i pairs imaging scanning expertise developed for our larger scanners with an innovative, compact design to create the most powerful presentation scanner on the market. The addition of Digimarc Barcode decoding makes the Magellan 1500i scanner uniquely capable of handling both current and future scanning needs.

The Magellan 1500i uses a high performance megapixel sensor and custom optics to create a large reading area capable of reading at distances up to 25 cm and with 1D sweep speeds up to 1.5 m/s. Powerful decoding algorithms provide unmatched performance on a variety of 1D and 2D labels, including hard-to-read, truncated and damaged codes. The large reading area and sweep performance of the Magellan 1500i scanner makes scanning easy and intuitive even for novice users.

The consistent, comfortable illumination enables seamless reading of 1D and 2D bar codes from printed or mobile sources while reducing reflection and eliminating flickering that can cause operator discomfort.

Datalogic’s Motionix™ motion-sensing technology enables the scanner to intuitively switch into hand held mode when the device is picked up. This turns on an LED aimer, while ‘Green Spot’ technology provides good-read confirmation directly on the code. When placed back on the counter, the scanner seamlessly returns to stand mode.

With its small footprint and attractive design, the Magellan 1500i scanner compliments any point of sale or service environment. Classic black and white enclosures pair with a variety of mounting options to make this a versatile, powerful product in an attractive, compact package.

Scanning
Type Fixed bar code reader
Scanner type 2D
2D (matrix & stacked) barcodes supported Aztec Code, Data Matrix, MaxiCode, QR Code
Sensor type LED
Optical sensor resolution (W x H) 1280 x 800 pixels
Light levels (direct sunlight) 0 - 86.1 lx
Tilt reading angle 0 - 360°
Pitch reading angle -65 - 65°
Yaw reading angle -75 - 75°
Scanner resolution 0.13 mm
Ports & interfaces
Connectivity technology Wired
Standard interfaces USB
USB version 2.0
Performance
Product colour Black
Housing material Plastic
International Protection (IP) code IP52
Buzzer Yes
Image formats supported BMP, JPEG
Certification EN62471, IEC62471
Power
Power source type USB
Input voltage 5 V
Power consumption 500 mA
Weight & dimensions
Width 60 mm
Depth 75 mm
Height 150 mm
Weight 240 g
Operational conditions
Operating relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Technical details
Compliance certificates RoHS
Logistics data
Harmonized System (HS) code 84716070
