Cisco Secure Firewall: Firepower 1140 Security Appliance with ASA Software, 8-Gigabit Ethernet (GbE) Ports, 4 SFP Ports, Up to 6 Gbps Throughput, 90-Day Limited Warranty (FPR1140-ASA-K9)

Secure Firewall: Firepower 1140 Security Appliance with ASA Software, 8-Gigabit Ethernet (GbE) Ports, 4 SFP Ports, Up to 6 Gbps Throughput, 90-Day Limited Warranty (FPR1140-ASA-K9)

---

The Cisco Secure Firewall with ASA software provides robust, proven Layer 3 and 4 security control. Ideal for small and medium-sized offices, this 1RU firewall includes support for advanced remote access VPN termination, plus BGP and OSPF routing functions. When Layer 7 application control and advanced threat defence are also required, select instead the Firepower 1140 appliance with FTD software.

---

Data transmission
Maximum firewall connections	400000
Maximum firewall connections per second	100000
IPSec VPN throughput	1.2 Gbit/s
Firewall throughput	2.2 Gbit/s

Performance
Processor cores	16
Processor family	Intel
Built-in processor	Yes

Network
Wi-Fi	No

Security
Stateful Packet Inspection (SPI)	Yes

Protocols
Supported network protocols	SMTP

Management features
URL filtering	Yes

Ports & interfaces
SFP module slots quantity	4
Number of console ports	1
Console port	RJ-45
Ethernet LAN (RJ-45) ports	8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Connectivity technology	Wired

Storage
SSD capacity	200 GB
Storage media type	SSD

Design
Form factor	1U
Rack mounting	Yes

Power
Power consumption (max)	100 W
Input current	2 A
AC input frequency	50 - 60 Hz
AC input voltage	100-240 V

Logistics data
Harmonized System (HS) code	85176990
Country of origin	Mexico
Quantity per pack	1 pc(s)

Operational conditions
Operating altitude	0 - 3000 m
Storage relative humidity (H-H)	10 - 90%
Operating relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight & dimensions
Height	43.7 mm
Depth	436.9 mm
Width	268.7 mm

Packaging data
Package weight	5.78 kg
Package depth	1409.7 mm
Package height	457.2 mm
Package width	990.6 mm

Other features
Firewall throughput	2200 Mbit/s
