Cisco
Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), White Dipole (1 Port), RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-R=)
Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), White Dipole (1 Port), RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-R=)
Regular price
£39.36 GBP
Regular price
Sale price
£39.36 GBP
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
SKU:AIR-ANT2524DW-R=
190 in stock
- OMNIDIRECTIONAL WI-FI ANTENNA: 2 dBi (2.4 GHz)/4 dBi (5 GHz); white dipole (1 port); for use with Aironet 1830, 1850, 2800 and 3800 Series and Cisco Catalyst 9115AX, 9120AX and 9130AX Series access points
- CONNECTION AND MOUNT: RP-TNC connector
- 360-DEGREE RADIATION PATTERN: Intended for deployment when coverage in all directions from the antenna is required
- PERFORMANCE: Designed for improved coverage
- PEACE OF MIND: 1-year limited hardware warranty
Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), White Dipole (1 Port), RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-R=)
The Cisco Aironet AIR-ANT2524DW-R= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved coverage and performance in mind. This FCC-approved omnidirectional antenna provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions from the antenna is required.
Performance | |
---|---|
Horizontal beam width (5 GHz) | 39° |
Horizontal beam width (2.4 GHz) | 63° |
Impedance | 50 Ω |
Antenna gain (2.4 GHz) | 2 dBi |
Antenna gain (5 GHz) | 4 dBi |
Frequency band | 2.4/5 GHz |
Antenna gain level (max) | 4 dBi |
Features | |
---|---|
Product colour | Grey |
Country of origin | China |
Purpose | Indoor |
Voltage Standing Wave Ratio (VSWR) | 2:1 |
Antenna connector type | RP-TNC |
Connector gender | Male |
Antenna type | Omni-directional antenna |
Operational conditions | |
---|---|
Storage temperature (T-T) | -40 - 85 °C |
Operating temperature (T-T) | -20 - 60 °C |
Weight & dimensions | |
---|---|
Package weight | 136.05 g |
Package height | 49.3 mm |
Package depth | 184.2 mm |
Package width | 152.4 mm |
Weight | 38.5 g |
Depth | 168.5 mm |
Width | 21 mm |
Packaging content | |
---|---|
Packaging content | AIR-ANT2524DW-R Antenna |
Quantity per pack | 1 pc(s) |
Logistics data | |
---|---|
Harmonized System (HS) code | 85177100 |
Other features | |
---|---|
Frequency range | 2.4 - 2.5GHz, 5.15 - 5.85GHz |
