Cisco

Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), 1 Port, Direct Mount, RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-RS=)

Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), 1 Port, Direct Mount, RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-RS=)

£61.28 GBP
£61.28 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

AIR-ANT2524DW-RS=

Low stock: 3 left

  • OMNIDIRECTIONAL WI-FI ANTENNA: 2 dBi (2.4 GHz)/4 dBi (5 GHz); white dipole (1 port); can be used with the Aironet 1830, 1850, 2800 and 3800 Series and Cisco Catalyst 9115AX, 9120AX and 9130AX Series access points
  • CONNECTION AND MOUNT: DART RP-TNC connector; direct connect to access point
  • 360-DEGREE RADIATION PATTERN: Intended for deployment when coverage in all directions from the antenna is required
  • PERFORMANCE: Designed for improved coverage
  • PEACE OF MIND: 1-year limited hardware warranty
Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), 1 Port, Direct Mount, RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-RS=)

The Cisco Aironet AIR-ANT2524DW-RS= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved performance in mind. It provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions is required. This FCC-approved omnidirectional antenna includes circuitry to enable self-identification of the antenna by the Cisco Catalyst 9100 Access Points.

Performance
Horizontal beam width (5 GHz) 39°
Horizontal beam width (2.4 GHz) 63°
Impedance 50 Ω
Antenna gain (2.4 GHz) 2 dBi
Antenna gain (5 GHz) 4 dBi
Frequency band 2.4/5 GHz
Antenna gain level (max) 4 dBi
Features
Product colour White
Compatible products Cisco Catalyst 9115AX, 9120AX, 9130AX
Country of origin Malaysia
Purpose Indoor
Voltage Standing Wave Ratio (VSWR) 2:1
Polarization Dual polarization
Antenna connector type RP-TNC
Connector gender Male
Antenna type Omni-directional antenna
Operational conditions
Storage temperature (T-T) -40 - 85 °C
Operating temperature (T-T) -20 - 60 °C
Weight & dimensions
Package weight 108.84 g
Package height 49.3 mm
Package depth 184.2 mm
Package width 152.4 mm
Packaging content
Manual Yes
Packaging content AIR-ANT2524DW-RS Antenna
Quick installation guide Yes
Quantity per pack 1 pc(s)
