Cisco 2960-CX Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White

Cisco 2960-CX Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White

£162.82 GBP
£162.82 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

WS-C2960CX-8PC-L-RFB

Low stock: 2 left

  • Managed L2/L3 Web-based management Telnet, RIP, SNMP, NTP, TACACS+, RMON, HTTP, RADIUS
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 8 Console port: RJ-45
  • 1000BASE-T, 100BASE-T, 10GBASE-T
  • Switching capacity: 24 Gbit/s
  • Power over Ethernet (PoE)
Catalyst 2960CX-8PC-L Network Switch, 8 Gigabit Ethernet Ports, 8 PoE+ Outputs, 124W PoE Budget, two 1 G SFP and two 1 G Copper Uplinks, Enhanced Limited Lifetime Warranty (WS-C2960CX-8PC-L)

The Cisco Catalyst 2960CX-8PC-L Network Switch is ideal for high-speed data connectivity, Wi-Fi backhaul and PoE+ connectivity in places where space is at a premium. Featuring a compact design and quiet, fanless operation, this managed switch can come out of the server room and be placed closer to users, meaning shorter cable runs and greater flexibility for your network deployment.

Management features
Switch type Managed
Switch layer L2/L3
Quality of Service (QoS) support Yes
Web-based management Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity 2
SFP+ module slots quantity 2
Console port RJ-45
Power connector DC-in jack
Network
Networking standards IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3z
10G support No
Copper ethernet cabling technology 1000BASE-T, 100BASE-T, 10GBASE-T
Full duplex Yes
Rate limiting Yes
Spanning tree protocol Yes
Link aggregation Yes
VLAN support Yes
Number of VLANs 4000
Data transmission
Switching capacity 24 Gbit/s
Forwarding rate 17.9 Mpps
Jumbo frames support Yes
Jumbo frames 9198
Security
DHCP features DHCP server
IGMP snooping Yes
Multicast features
Multicast support Yes
Protocols
Management protocols Telnet, RIP, SNMP, NTP, TACACS+, RMON, HTTP, RADIUS
Supported network protocols ICMP, ARP, BOOTP, OSPF, DHCP
Design
Rack mounting No
Product colour White
LED indicators Yes
Market segment Business
Country of origin China
Certification FCC, CE, CFR 47, EN 55022, EN 55024, AS/NZS, CISPR22:2004, EN55022, VCCI, KCC, ANATEL, CCC, GOST
Performance
Internal memory 512 MB
Flash memory 128 MB
Mean time between failures (MTBF) 569530 h
Power
AC input voltage 100 - 240 V
Input current 1.5 - 3.25 A
Power consumption (typical) 24.5 W
Power plug type Type C
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet plus (PoE+) ports quantity 8
Total Power over Ethernet (PoE) budget 124 W
Operational conditions
Operating temperature (T-T) -5 - 45 °C
Storage temperature (T-T) -25 - 70 °C
Operating relative humidity (H-H) 5 - 95%
Storage relative humidity (H-H) 5 - 95%
Operating altitude 0 - 3048 m
Non-operating altitude 0 - 4000 m
Heat dissipation 648.3 BTU/h
Weight & dimensions
Width 269 mm
Depth 238 mm
Height 44.4 mm
Weight 2.27 kg
Packaging data
Package width 327.7 mm
Package depth 349.2 mm
Package height 160.3 mm
Package weight 2.27 kg
Logistics data
Quantity per pack 1 pc(s)
Harmonized System (HS) code 85176990
