Avocor AVH-7520 H-Series - 75" 4K Pcap LED Interactive Display
Avocor AVH-7520 H-Series - 75" 4K Pcap LED Interactive Display
Couldn't load pickup availability
SKU:AVH-7520
Low stock: 1 left
- 4K Ultra HD
- 16:9 aspect ratio
- Sleek design with an ultra-thin Bezel
- Zero parallax optically bonded glass surface for pixel-perfect inking
- Presence Detection Sensor
- Single Type-C connectivity delivering audio, video, touch, Ethernet and power
- Intel OPS PC slot for expanded functionality
- Avocor UiQ - smart touch enabled dynamic user interface
- FUSE - Remote management software platform for AV/IT Managers
- Elegant Design for Contemporary Spaces
- Optimized Display for Immersive Experiences
- Advanced Touch Technology for Collaborative Work
- Seamless Integration and Versatile Connectivity
- Dynamic Software for Enhanced Communication
The Avocor H Series redefines interactive displays for modern workspaces, emphasizing seamless collaboration and connectivity. With its ultra-thin bezel and sophisticated design, it integrates effortlessly into professional environments, enhancing aesthetic appeal and functional utility. This sleek design, devoid of visible buttons or inputs, maintains a sophisticated and uncluttered profile, perfectly complementing the aesthetic standards of today's workspaces. Across all models (65", 75", and 86"), the H Series boasts a high-resolution 4K display, bringing life to content with unparalleled clarity.
The Avocor H Series has a premium feel that will enhance any meeting room, and the technology needed to accommodate high collaboration in hybrid workspaces.
Ensure every in-person and remote interaction provides a natural and intuitive meeting experience with the Avocor H Series, the perfect solution for organizations that demand both a luxury aesthetic and a high performing functional workspace.
In the hybrid work era, the H Series excels in corporate settings with its sleek design and advanced touch technology, enhancing collaboration among remote and in-office teams. Its easy installation and FUSE-powered remote management streamline IT operations, while diverse connectivity options ensure seamless device integration. The addition of Montage and Rise Vision transforms idle screens into dynamic communication hubs, keeping all team members engaged and informed, thus embodying a versatile solution for modern corporate challenges.
| Display | |
|---|---|
| Display diagonal | 190.5 cm (75") |
| Display brightness | 400 cd/m² |
| Display number of colours | 1.07 billion colours |
| Display resolution | 3840 x 2160 pixels |
| Anti-glare screen | Yes |
| HD type | 4K Ultra HD |
| LED backlight | Yes |
| Panel type | LCD |
| LED backlighting type | Direct-LED |
| Native aspect ratio | 16:9 |
| Contrast ratio (typical) | 5000:1 |
| Response time | 6.5 ms |
| Maximum refresh rate | 60 Hz |
| Touchscreen | Yes |
| Touch technology | Multi-touch |
| Touchscreen type | Capacitive |
| Number of simultaneous touchpoints | 40 |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Screen glass thickness | 2 mm |
| Palm rejection | No |
| Palm erase | No |
| Pen & touch differentiation | Yes |
| Audio | |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Speaker power | 16 W |
| Built-in microphone | No |
| Network | |
|---|---|
| Wi-Fi | Yes |
| Antenna type | 1x1 |
| Ethernet LAN | Yes |
| Wake-on-LAN ready | Yes |
| Ports & interfaces | |
|---|---|
| HDCP | Yes |
| HDCP version | 2.3 |
| USB 2.0 Type-B Touch ports quantity | 3 |
| USB 2.0 Type-A hub ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| USB Type-C ports quantity | 1 |
| HDMI ports quantity | 4 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDMI output ports quantity | 1 |
| HDMI version | 2.0 |
| USB Power Delivery up to | 100 W |
| USB Power Delivery | Yes |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Line-out | Yes |
| OPS slot | 1 |
| S/PDIF out port | Yes |
| Audio output | 1 |
| RS-232 ports | 1 |
| Ergonomics | |
|---|---|
| Product colour | Brushed steel |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Wall mountable | Yes |
| Fanless | Yes |
| Performance | |
|---|---|
| Ambient light sensor | Yes |
| Proximity sensor | Yes |
| Power | |
|---|---|
| Power consumption (max) | 257 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage temperature (T-T) | 20 - 85 °C |
| Weight & dimensions | |
|---|---|
| Width | 1714 mm |
| Depth | 80 mm |
| Height | 1002 mm |
| Weight | 48 kg |
| Packaging data | |
|---|---|
| Package width | 1863 mm |
| Package depth | 225 mm |
| Package height | 1130 mm |
| Package weight | 69 kg |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
|---|---|
| USB cable length | 3 m |
| Cables included | HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C |
| Quick start guide | Yes |
| Mounting brackets included | Yes |
| Batteries included | Yes |
| Remote control included | Yes |
| Stylus included | Yes |
| Stylus pen type | Passive |
| Number of stylus pens | 2 |
| Logistics data | |
|---|---|
| Warranty period | 3 year(s) |
| Country of origin | China |
