Lindy 50m 4 Port USB 2.0 Cat.6 Extender

Lindy 50m 4 Port USB 2.0 Cat.6 Extender

Regular price £123.17(incl. VAT)
Regular price Sale price £123.17(incl. VAT)
Sale Sold out
Tax included. Shipping calculated at checkout.

SKU:42681

11 in stock

  • Extend 4 USB 2.0 ports up to 50m using low cost Cat. 5e/6 network cable (not included)
  • Power over Cable requires a single power supply to be connected to the transmitter only
  • Supports USB 2.0 High Speed and USB 1.1 Full Speed / Low Speed
  • Plug and Play installation
  • 2 year warranty
50m 4 Port USB 2.0 Cat.6 Extender

This Lindy USB 2.0 Cat.6 Extender can be used to extend the distance between four USB peripheral devices and the host computer by up to 50m.

A standard, low cost Cat.5e/6 network cable (not included) is used to bridge the connection between the transmitter and the receiver unit. For best performance and compatibility, we recommend the use of solid core patched cables.

The Extender features Power over Cable, which requires a single power supply only to be connected to the transmitter unit. This handy feature allows the receiver unit and connected devices to be located more freely as no power supply is required. With robust metal housing and integrated mounting brackets this Extender is the ideal solution for industrial environments.

Performance
Plug and Play Yes
Chipset (transmitter) NS1021
Cable types supported Cat5, Cat5e, Cat6
Data transfer rate 480 Mbit/s
Maximum transfer distance 50 m
Type Network transmitter & receiver
Ports & interfaces
Contact material Phosphor bronze
Connector contacts plating Gold
Connector material Gold
DC-in jack Yes
USB 2.0 ports quantity 5
RJ-45 ports quantity (receiver) 1
RJ-45 ports quantity (transmitter) 1
Ethernet LAN (RJ-45) ports 2
Design
Certification CE, UKCA, FCC, RoHS, REACH
LED indicators Yes
Housing material Metal
Product colour Black
Power
Included power plug types AU, EU, UK, US
Power note 3.5/1.35mm DC
Power over Ethernet (PoE) Yes
Output current 0.5 A
Output voltage 24 V
External power adapter Yes
Operational conditions
Storage relative humidity (H-H) 0 - 90%
Operating relative humidity (H-H) 0 - 90%
Storage temperature (T-T) -20 - 80 °C
Operating temperature (T-T) 0 - 70 °C
Weight & dimensions
Receiver height 2.3 cm
Receiver depth 6.4 cm
Receiver width 11 cm
Transmitter height 2.3 cm
Transmitter depth 6.7 cm
Transmitter width 6 cm
Weight 415 g
Packaging content
Manual Yes
Cables included USB Type-A to USB Type-B
Packaging data
Package height 50 mm
Package volume 600 cm³
Package depth 155 mm
Package width 215 mm
Package type Box
Logistics data
Harmonized System (HS) code 85176990
